IQnav + (Discontinued)

IQnav+™ is a premier test solution for GPS and GLONASS enabled devices. It provides signal generation capability over a wide power range supporting both conducted and radiated testing.

Suited for cellular, module and Personal Navigation Device (PND) manufacturers.

GPS, GLONASS & FM Manufacturing Test

• For GPS and GLONASS testing: All key parameters for GPS signal creation are user-definable, including navigation data, space vehicle number and Doppler (+/- 10 kHz)
• Supports signal output levels down to -145 dBm through a single test port connector
• Provides comprehensive test coverage for both FM waveform generation and signal analysis

Navigation Test Flexibility

• One- and six-channel models with +/- 10 kHz Doppler shift capability
• Performs single-connection Carrier-to-Noise (C/N) and location-fix tests
• Synthetic Power Sweep (SPS) verifies 6 levels in one sensitivity measurement

Manufacturing Friendly

• Power range (-60 to -145 dBm) and CW mode allows simple power level verification to validate test station losses
• Consistent test yield and rapid debugging
• Software Defined Radio (SDR) Architecture
• SDR design approach allows 6-channel test performance for location lock testing

Technology Options

• GPS
• GLONASS

When & Where to Use the IQnav+ for Testing?

• In lab and manufacturing environments
• For products in the PCB-level manufacturing or final product test lifecycle stages
• For Navigation-enabled mobile or IoT devices
